8514-296-001 REV K page 77
COMM ERROR4
VFD Non
Existent or
communication
fault
Condition
This error is when the washer controller
cannot communicate with the drive.
Delay Delay time is 2 seconds
Action
Stop the machine and clear the cycle. Keep
the door locked until the machine has
stopped moving and then unlock the door.
Solution
Check the data communication cable
between the washer computer and the
variable frequency drive (VFD).
Step 1: Make sure the cable did not
become unplugged during operation. Step
2: Make sure that the cable is not being
pulled sideways at either the washer
controller, or the VFD, plug end. If both
ends of the communications cable are
plugged in the washer computer and VFD
and there is no tension on the
communications cable pulling it from side
to side, then replace the cable. Step 3:
Inspect both female connection points at
PCB controller and at VFD. These may
need replacement if they cannot be reset.
COMM ERROR5
VFD
Communication
Fault
Condition
This error is caused when the control
detects no cylinder motion when it should
be rotating.
Delay Immediate
Action
The washer cycle will continue but without
any cylinder motion. “COMM_ERROR_5”
will flash three times then wait 30 seconds
and then repeat. No change in operation.
Solution
Check the VF drive enable wire
connections from relay board to drive.
SLOW DRAIN
ERROR
Drain Error Condition
This error is when an empty water level is
not reach within 7 minutes.
Delay Immediate
Action
The washer cycle will continue. Do not spin
the tumbler without reaching an empty
water level. If empty water level is not
reached, agitate during the normal spin
time.
Solution
Check VFD fault light before turning off
power. Check to ensure the drain valve is
operating properly (slow drain has
potential to cause this code). Check to
ensure the pressure switch tube is clear of
any blockage, and the pressure switch is
operating properly. Check the pressure
switch harness.
SPIN STOP
Stop Error Condition
This error is when the washer does not
stop spinning within 150 seconds after
