Chapter 3 Ports and Connectors
HDMI
The HDMI interface which carries both digital audio and video signals is used to connect a LCD
monitor or digital TV that has the HDMI port.
HDMI
Note:
The graphics features are controlled by CPU. When HDMI and LVDS displays
simultaneously, the system board transmits video signals from HDMI port only. The
LVDS works on the system board will make the screen dark.
Mini USB
Mini USB
The Mini USB is a device that can act as client role. It indicates the concept of one-to-one
connection between two devices which are connected directly in order to transfer data
bilaterally.
