DFI KS211 - Specifications

www.dfi .com
7
Chapter 1 Introduction
EXPANSION
SLOTS
• 1 Mini PCIe slot (DFI Proprietary)
- Supports half size Mini PCIe card
- Supports USB interface for 3G module
• 1 SIM card slot
POWER • 9~30Vdc (+/-10%) power input voltage
FRONT PANEL
PROTECTION
• IP65 (Dust Tight; Water Proof protection)
CONSTRUCTION
• Aluminum front bezel, rugged metal housing
MOUNTING • Wall mount (VESA 75x75)
• Panel mount (Mounting clamp)
ENVIRONMENT • Temperature
- Operating: -15
o
C ~ 60
o
C
- Storage: -30
o
C ~ 80
o
C
• Relative Humidity
- 95% RH at 60
o
C
DIMENSIONS • 235mm x 150mm x 40.80mm (W x H x D)
WEIGHT
• 2.10 kg
OS SUPPORT • Android 2.3
• LTIB Linux 2.6.35.3
Specifications
KS211
PROCESSOR • Freescale i.MX535
- ARM Cortex-A8 core
- Processor speed: up to 1GHz
SYSTEM MEMORY • DDR3 onboard
• Onboard
memory
- 1GB: standard
- 2GB: option
LCD and
TOUCH SCREEN
• 7” (800x480) WVGA TFT touch screen LCD
• Supports touch screen
- TI
®
TSC2004 touch screen controller
• 400 NITS
• 4-Wire Resistive touch screen
STORAGE • 8Mbit EEPROM (option)
•
1 SD/MMC socket
• Supports 4GB (standard), 8GB and 16GB eMMC onboard
ONBOARD LAN
FEATURES
• SMSC 8710 10/100 Ethernet transceiver
AUDIO • SGTL5000 2-channel audio codec
• 2 built
-in 2W speakers (left and right sides)
• 1 Line-out
GPIO
• 1 12-bit GPIO connector (6 bit in/6 bit out, with power)
I/O PORTS • Front
- 1 Power LED
- 4 function keys
• Bottom
- 1 DB-9 RS232/422/485 serial port
- 1 HDMI port
- 1 Mini USB port (device Type B)
- 2 USB 2.0/1.1 ports (Type A)
- 1 Line-out jack
- 12-bit GPIO (2 7-pole terminal blocks)
- 1 2-pin 9-30V DC-in jack
- 1 power switch
- 1 LAN port
• Side
- 2 built-in 2W speakers (left and right sides)
• Top
- 1 SD/MMC card socket
Chapter 1
