Introduction
11
• 2 RJ45 LAN ports (for “nF4 SLI” and “nF4 Ultra” models only)
1 RJ45 LAN port (for “nF4” model only)
• 6 USB 2.0/1.1 ports
I/O Connectors
• 2 connectors for 4 additional external USB 2.0/1.1 ports
• 1 connector for 1 external IEEE 1394 port
• 1 connector for 1 external serial port
• 1 front audio connector for external line-out and mic-in jacks (on
the Karajan audio module)
• 1 CD-in internal audio connector (on the Karajan audio module)
• 1 S/PDIF connector for optical cable connection
• 1 IR connector
• 8 Serial ATA connectors (for “DR” models only)
4 Serial ATA connectors (for “D” models only)
• 2 IDE connectors
• 1 floppy connector
• 1 24-pin ATX power connector
• 1 4-pin ATX 12V power connector
• 2 4-pin 5V/12V power connectors (FDD-type and HDD type)
• 1 front panel connector
• 5 fan connectors
• 4 diagnostic LEDs
• 1 diagnostic LED connector for external 4 diagnostic LEDs
display (for LANPARTY nF4 SLI-DR only)
• EZ touch switches (power switch and reset switch)
PCB
• ATX form factor
• 24cm (9.45") x 30.5cm (12")
