Hardware Installation
1
CPU
Overview
The system board is equipped with a surface mount 939-pin CPU
socket. This socket is exclusively designed for installing an AMD CPU.
Installing the CPU
1. Make sure the PC and all other peripheral devices connected to
it has been powered down.
2. Disconnect all power cords and cables.
3. Locate the 939-pin CPU socket on the system board.
