DFI LanParty nF4 - Setting the Jumpers

68
2
Hardware Installation
1
X
2-3 On: SLI mode
The illustration below shows the bandwidth of the PCI Express slots
when set in SLI mode.
Bandwidth
x4
x8
N. C.
x8
PCIE2
PCIE1
PCIE3
PCIE4
Setting the Jumpers
The jumpers in the illustration below are used to switch between SLI
mode and Single VGA mode.
SLI Mode
