Hardware Installation
1
312
312
JP1 is used to safely reboot the system whenever the system hangs
and you are unable to restart the system.
1. Power-off the system and unplug the power cord.
2. Set JP1 pins 2 and 3 to On. Wait for a few seconds then set
JP1 back to its default setting, pins 1 and 2 On.
3. Plug the power cord and power-on the system. The system will
reboot normally without losing all data stored in the CMOS.
Safe Boot
X
JP1
2-3 On:
Safe boot
1-2 On:
Default
