DFI NB78-BC - Jumpers; Clear CMOS Data - JP2; Cpus Front Side Bus - JP1

8
Quick Setup Guide

Quick Setup
Guide
1.2 Jumpers
1.2.1 Clear CMOS Data - JP2
1-2 On:
Normal (default)
2-3 On:
Clear CMOS Data
12 3
12 3
1.2.2 CPUs Front Side Bus - JP1
3
2
1
3
2
1
3
2
1
1-2 On: Auto
(default)
2-3 On: 100MHz
All Off: 133MHz
Important:
Overclocking may result in the processors or systems instability and
is not guaranteed to provide better system performance.
Clear CMOS
(JP2)
12
3
CPU FSB select
(JP1)
1
2
3
