The following is the pin assignments for the module’s HD15 female connector.
Pin on Protocol
1 CAN-LOW (channel 2)
2 Signal Ground (channel 1)
3
Not connected
4
Not connected
5 Signal Ground (channel 2)
6 CAN-High (channel 2)
7 SWCAN (channel 1)
8
Not connected
9
Not connected
10 V– IN/Power Ground
11
Not connected
12 PASSTHRU1
13 PASSTHRU2
14
Not connected
15 V+ IN (input voltage: 6 – 32 VDC)
Table 5: HS CAN / SW CAN connector pin assignments
