31
Dialogic
®
SS7G2x Signaling Server SGW Mode User Manual Issue 4
DATE
Calendar date, in the format:
xxxx-yy-zz
where:
• xxxx – 4 digit year
• yy – 2 digit month
• zz – 2 digit day
xxxx – 1990 to 2037
yy – 01 to 12
zz – 01 to 31
DBITS Number of data bits on V.24 port 7 or 8 Default = 8
DEST Signaling Gateway Destination Point ID 1 to 512
DIRECTORY Directory name on a remote data centre.
0 to 12
<text character>
DISCARD Whether data can be discarded Y or N Default = N
DOMAIN Domain
One of:
•IP
•MTP
DPC SS7 destination point code 0 to 16777215
DTYPE
The type of saving/loading operation to be
performed from a remote data centre. See
Section 5.2, “Remote Operations” on
page 37.
One of:
•SOFTWARE
•CONFIG
•LICENSE
DUPLEX
Specifies whether a connection is duplex (Y)
or simplex (N).
Y or N Default = N
END
Specifies whether the Signaling Gateway’s
end of the SIGTRAN link is acting as either a
client (C) or a server (S).
C or S
EQU
Signaling processor hardware identifier in
the format:
x-y
where:
• x = board position (BPOS)
• y = signaling link within the board.
NOTE: V.11 links can only use processors
1 and 2.
x – 1 to 3
y – 1 to 64
ETH
Ethernet port number in the range 1 to 4,
where:
• ETH=1 corresponds to physical port
ENET 1
• ETH=2 corresponds to physical port
ENET 2
• ETH=3 corresponds to physical port
ENET LNK A
• ETH=4 corresponds to physical port
ENET LNK B
1 to 4
FF
PCM frame format:
• G704 – Normal E1 format described in
G.704
• CRC4 – Normal E1 format with CRC4
checksum generation
• CRC4C – Normal E1 format with CRC4
checksum generation. Compatible with
non-CRC4 operation.
• SF – 12 frame multiframe (D3/D4)
• ESF – 24-frame multiframe
• CRC6 – ESF format with CRC6
checksum generation
• CRC4G706 – CRC4 G.706 compatible
mode
NOTE: Out of CRC4-multiframe, E-Bits are
transmitted as zeroes.
One of:
• G704
•CRC4
•CRC4C
•SF
•ESF
•CRC6
• CRC4G706
Default =
• G704 for E1
•SF for T1
FILE File name on a Remote Data Centre (RDC)
0 to 12
<text character>
Table 2. Parameter Definitions (Continued)
Name Description Range Notes
