Chapter 5 Parameter Definitions
SPEED
The speed of an Ethernet port.
The values 10, 100, 100 select 10 MHz, 100
MHz and 1 GHz respectively. An “H”
appended to the value indicates half-duplex
operation; values without the appended “H”
are full-duplex operation.
One of:
•AUTO
10
100
1000
10H
100H
1000H
Default = AUTO
SRTX
Number of times a packet of SIGTRAN
information can be retransmitted before
determining that the SIGTRAN link has gone
out of service
2 to 10
SS7MD
SS7 signaling mode:
ITU14 – ITU operation with 14 bit Point
Code
ITU16 – ITU operation with 16 bit Point
Code
ITU24 – ITU operation with 24 bit Point
Code
ANSI – ANSI operation with 24 bit Point
Code
One of:
ITU14
ITU16
ITU24
•ANSI
STS
A timeslot within a PCM interface on a board
used for monitoring information sent by the
monitored object. The format is:
xx-y-zz
where:
xx = board position (BPOS)
y = PCM within a board
zz = timeslot
xx – 1 to 3
y – 1 to 4
zz – 1 to 31
SUBNET
Subnet mask for the network to which the
Signaling Gateway is connected specified
using dot notation, that is, www.xxx.yyy.zzz
www – 0 to 255
xxx – 0 to 255
yyy – 0 to 255
zzz – 0 to 255
Default =
255.255.255.0
SUBNET2
2
nd
Subnet mask for the network to which
the Signaling Gateway is connected
specified using dot notation, that is,
www.xxx.yyy.zzz
www – 0 to 255
xxx – 0 to 255
yyy – 0 to 255
zzz – 0 to 255
Default =
255.255.255.0
SUBNET3
3
rd
Subnet mask for the network to which
the Signaling Gateway is connected
specified using dot notation, that is,
www.xxx.yyy.zzz
www – 0 to 255
xxx – 0 to 255
yyy – 0 to 255
zzz – 0 to 255
Default =
255.255.255.0
SUBNET4
4th Subnet mask for the network to which
the Signaling Gateway is connected
specified using dot notation, that is,
www.xxx.yyy.zzz
www – 0 to 255
xxx – 0 to 255
yyy – 0 to 255
zzz – 0 to 255
Default =
255.255.255.0
SYNCPRI
The priority the PCM is given to provide
clock synchronization:
0 – Indicates never provide clock
synchronization
1 – Highest priority that PCM should
provide clock synchronization
32 – Lowest priority, that is, other PCMs
have precedence
0 to 32 Default = 0
SYSID System identity
0 to 12
<text character>
SYSREF The system reference number 0 to 999 Default = 0
SYSTYPE The type of system to be run
One of:
•SGW
•DSC
•SIU
Table 2. Parameter Definitions (Continued)
