PROLYTE ANALYZER
Fill Plug
Fill Solution
Membrane Assembly
Sam
p
le Detector
Potassium Electrode
Sodium Electrode
Chloride Electrode
Electrode Housing
Locating
Pins
Reference
Electrode
Figure P4– Electrode Housing Assembly
9
