PROLYTE ANALYZER
17
2.h Serial Communication Verification
1. Connect the proLYTE analyzer to a device with a known working serial port. Use
a known good proLYTE serial cable, part no. ME-1334D. Make cross
connections as required (e.g. 2 to 3; 4 to 5).
2. Refer to the following serial interface specifications.
Serial Interface Specifications
Serial Cable Settings
Connector 25-pin, D-Sub Male
Pin Type RS-232
Pin Assignments
Pin 1 Chassis, Not Connected
Pin 2 T x D
Pin 3 R x D
Pin 4 RTS
Pin 5 CTS
Pin 7 Signal Ground
RS-232 Protocols
Transmission Rate 1200 baud
Bit Configuration 8 data bits, 1 stop
Bit Parity None
Control Codes None
All lines end with Carriage
return line feed (CRLF)
All transmission is ASCII string
3. When correctly linked the proLYTE will transmit to the external device all of the
data that is printed by the proLYTE printer, in the same format.
