PROLYTE ANALYZER
3.g Printer Removal
1. Remove the printer lid from the printer.
2. Remove the paper roll from the printer bay.
3. Remove the rear housing.
4. Detach the printer cable from the retaining clamps located along the right side of the
CPU board.
5. Detach the two screws using a Phillips head screw driver. Remove the printer body, as shown in
Figure P7.
6. Pull the printer cable up from behind the CPU board, while holding the printer body as shown in
Figure P8.
3.h Printer Installation
1. Slide the printer cable behind the CPU board.
2. Install the printer body into place. See Figure P8.
3. Attach the two screws using a Phillips head screw driver. See Figure P7.
4. Connect the printer cable to the CPU board.
5. Using scissors, cut the beginning of the paper roll into a “V” shape. Insert the paper into the feeder
slot inside the printer bay, and press the paper feed button.
6. Place the printer roll into the printer bay.
7. Place the printer lid onto the printer.
8. Attach the printer cable to the retaining clamps located along the right side of the CPU board.
