DV300/DV301B 30" Multimedia Information Display
Side View (Right)
DV300
1 Audio (L) Audio (L) for component video
2 Audio (R) Audio (R) for component video
3 Component Video Component video Y/Pb/Pr input
4 Composite Video Composite video CVBS input
5 Audio (L) Audio (L) for CVBS and S-Video
6 Audio (R) Audio (R) for CVBS and S-Video
7 S-Video S-Video input
8 RF 75Ω TV Antenna or CATV cable in
11
DV301B
1 Audio (L) Audio (L) for component video
2 Audio (R) Audio (R) for component video
3 Component Video Component video Y/Pb/Pr input
4 Composite Video Composite video CVBS input
5 Audio (L) Audio (L) for CVBS and S-Video
6 Audio (R) Audio (R) for CVBS and S-Video
7 S-Video S-Video input
Optimising Performance
• For best performance, ensure that your display settings are set at 1280x768, 60Hz.
Note: You can check the current display settings
by pressing the ‘MENU’ button once.
