Diamond Digital DV300 - Connecting to Cable TV

DV300/DV301B 30" Multimedia Information Display
Connect to DVD/VCR /VCD through component video (YPbPr)
Connecting to Cable TV
17
Antenna
18
COMPONENT VIDEO
(DVD/HD IN)
G/Y B/Cb/Pb R/Cr/Pr
AUDIO
R
COMPONENT VIDEO
(DVD/HD IN)
CVBS L R S-VIDEO
Cable TV
Cable TV Signal Input
Back of Monitor TV
Round Cable
75Ω (ohm)
Cable TV Converter
Box Connection
300(ohm) to
75Ω (ohm) Adapter
Back of Monitor TV
Back of Monitor TV
Twin-Lead Wire
Round Cable 75Ω (ohm)
Combination
VHF/UHF
Antenna
(Outdoor
or Indoor)
U/V Combiner
300- to 75-ohm Adapter
L
