46
Main Item Control Item CMD Type
Value
(HEX)
Reply
(HEX)
Content CMD (HEX) Remark
Timer Mode TMS W/R
00 00 Everyday Mode
54 4D 53 01 01 Workday Mode
02 02 User Mode
RTC
Enable AEN W/R 00~7F 00~7F
In User Mode:
Set bit0 to 1: Sunday
Enable
Set bit1 to 1: Monday
Enable
Set bit2 to 1: Tuesday
Enable
Set bit3 to 1:
Wednesday Enable
Set bit4 to 1:
Thursday Enable
Set bit5 to 1: Friday
Enable
Set bit6 to 1:
Saturday Enable
In Everyday Mode:
Set any bit0~6 to 1:
Mon-Sun. Enable
In Workday Mode:
Set bit0 to 1: Sunday
Enable
Set any bit1~5 to 1:
Mon-Fri. Enable
Set bit6 to 1:
Saturday Enable
41 45 4E
Disable AEF W/R 00~7F 00~7F
In User Mode:
Set bit0 to 1: Sunday
Disable
Set bit1 to 1: Monday
Disable
Set bit2 to 1: Tuesday
Disable
Set bit3 to 1:
Wednesday Disable
Set bit4 to 1:
Thursday Disable
Set bit5 to 1: Friday
Disable
Set bit6 to 1:
Saturday Disable
In Everyday Mode:
Set any bit0~6 to 1:
Mon-Sun. Disable
In Workday Mode:
Set bit0 to 1: Sunday
Disable
Set any bit1~5 to 1:
Mon-Fri. Disable
Set bit6 to 1:
Saturday Disable
41 45 46
