49
Main Item Control Item CMD Type
Value
(HEX)
Reply
(HEX)
Content CMD (HEX) Remark
HDMI2 EH2 W/R
00 00 1080P
45 48 32
01 01 4K30Hz
HDMI3 EH3 W/R
00 00 1080P
45 48 33 01 01 4K30Hz
02 02 4K60Hz
HDMI4 EH4 W/R
00 00 1080P
45 48 34 01 01 4K30Hz
02 02 4K60Hz
OPS EH5 W/R
00 00 1080P
45 48 35 01 01 4K30Hz
02 02 4K60Hz
DisplayPort1 ED1 W/R
00 00 1080P
45 44 31 01 01 4K30Hz
02 02 4K60Hz
DisplayPort2 ED1 W/R
00 00 1080P
45 44 32 01 01 4K30Hz
02 02 4K60Hz
Multi-
Source
Multi-
Source
Views Adjust
PSC W/R
00 00 OFF
50 53 43
01 01 PIP Small
02 02 PIP medium
03 03 PIP large
04 04 Dual View
05 05 Dual View Portrait
07 07 Quad View
PIP source
selection
PIN W/R
(refer to
MIN)
(refer to MIN)
Select the input source
of sub window 1 (refer
to MIN)
50 49 4E
PIO W/R
(refer to
MIN)
(refer to MIN)
Select the input source
of sub window 2 (refer
50 49 4F
