500 Range
51
8. APPENDIX ON BATTERIES
Comparison between models with batteries and models without battery:
MODELS WITHOUT BATTERY
MODELS WITH BATTERY
Reference
Characteristics
Reference
Characteristics
Power Source
4519006600
(MHFADIB6)
Without battery
charger
451100110000
(MHKFABAT1)
It includes a battery charger
Printer interface
4509012300 For DIBAL printer 4509013000
For EPSON printer
Printing Unit
49-1757 24V 105
EPSON 7,5 V
Batteries
- - - - It does not have any
FG2072112VFIAMM
ó
FGH20502FIAMM
1 x 12V / 7,2Ah
ó
1 x 12V / 5Ah
Connection to
electrical supply
- - - - Cable - - - - Cable without switch
Switches
1 Power switch 1 20
When the scale is connected to the electricity supply, regardless of whether it is switched on or
off, the battery is charging.
8.1. WORKING MODES OF THE 500 SERIES BATTERY
Depending on whether the scale is connected to the electricity supply source or not, regardless of whether
it is switched on or not, or during operation, the scale is in one of the following states:
‘0’ – cable disconnected, with the scale switched off: it is not being charged.
‘1’ - cable connected, with the scale switched off: it is being charged
‘2’ - cable disconnected, with the scale switched on: battery fed, it is being used up.
‘3’ - cable connected, with the scale switched on: mains supply, it is being charged.
8.2. BATTERY CONTROL PARAMETERS
The 500 RANGE battery models offer a parameter (BATTERY CONTROL) which allows you to select
consumption mode in which the battery will operate.
There are three possible values for this parameter:
0: Operation with no saving in consumption.
1: Operation with average savings in consumption.
2: Operation with maximum savings in consumption.
By default, the battery control parameter of the battery models of scale is set to 1. If the scale is not a
battery model, this parameter does not exist.
8.3. OPERATION DEPENDING ON THE BATTERY CONTROL PARAMETER
VALUE
8.3.1. Battery control to 1(default mode)
There is no saving in battery. The scale consumes the same as a scale operating without batteries.
