8.3.2. Battery control to 1(default mode)
There is average saving in battery.
The Backlight operates in timer mode, with a NON-MODIFIABLE timing of 10 seconds, in such a way
that, if there are no variations in the weight on the tray or in key pressing in this period of time, the
backlight switches off.
The RS-232 and USB Interfaces deactivate their power supply circuits. There is no serial
communication.
8.3.3. Battery control to 2
There is maximum savings in battery life.
The Backlight switches off and cannot switch itself on.
The Ethernet Controller disables itself and there are no Ethernet connections or communication to
M/S or PC.
The RS-232 and USB Interfaces disable their power supply circuits. There is no serial
communication.
8.4. MESSAGES AND INDICATORS IN BATTERY-RUN SCALE
8.4.1. Messages and indicator of battery load
When operating, the battery scale shows its status in relation to the battery through:
1. Messages: which appear on the display to indicate status, changes in status, alarms, etc.
2. Battery load indicator: battery icon on the display made up of segments. The segments are: a
contour icon in the shape of a battery containing 3 segments to indicate the load level.
The alarm messages display on the weighing screen only when it is in operation mode 2. (Cable disconnected,
scale on)
The battery indicator only displays on the weighing screen and disappears from all others. (Menus and
submenus, total cashier, discount on total, two forms of payment, etc.)
The battery-related messages that display on booting up the scale appear following the countdown and
will display for a few seconds the percentage of battery life in the following way:
“BATTERIE X%” where X is the battery level in %.
8.4.2. Messages and indicator depending on operation status
Sur le tableau suivant sont spécifiés les différents états dans lesquels le niveau de charge de la batterie
est affiché suivant la situation des segments, aussi bien en ce qui concerne le dessin en forme de pile
que les 3 segments intérieurs
