Diesse MINI-CUBE - Quality Control

Rev. 1.2 (12.2021) MINI-CUBE | SERVICE MANUAL 36
VES_ADJ_PED
1000
Multiplication factor to adjust the ESR result for pediatric
tubes
BL_HEIGH_3000_UL
590
Parameter for determining the exact volume of blood for
blood column height of 3mL
BL_HEIGH_1500_UL
255
Parameter for determining the exact volume of blood for
blood column height of 1.5mL
Correlation matrices of ESR results, respectively for normal tubes (N_PNT_CURVE) and for
pediatric tubes (N_PNT_CURVE_PED)
N_PNT_CURVE
6
N_PNT_CURVE_PED
5
DELTA.1
12
ESR.1
1
DELTA.1
20
ESR.1
8
DELTA.2
50
ESR.2
15
DELTA.2
40
ESR.2
15
DELTA.3
150
ESR.3
30
DELTA.3
50
ESR.3
20
DELTA.4
240
ESR.4
70
DELTA.4
100
ESR.4
100
DELTA.5
290
ESR.5
100
DELTA.5
110
ESR.5
100
DELTA.6
340
ESR.6
140
DELTA.6
0
ESR.6
0
DELTA.7
0
ESR.7
0
DELTA.7
0
ESR.7
0
DELTA.8
0
ESR.8
0
DELTA.8
0
ESR.8
0
Correction tables as a function of the volume detected in the test tube.
Correction factor on calculated ESR data Correction factor on raw data before ESR
N_PNT_CURVE_VOL_ADJ
5
N_VCF_1000 TO 1500 uL
1000
VOL.1
1000
FACT.1
200
N_VCF_1500 TO 2000 uL
1000
VOL.2
1500
FACT.2
150
N_DELTA_TSH
160
VOL.3
2000
FACT.3
125
P_VCF_1000 TO 1500 uL
1000
VOL.4
3000
FACT.4
100
P_VCF_1500 TO 2000 uL
1000
VOL.5
4000
FACT.5
90
P_DELTA_TSH
160
VOL.6
0
FACT.6
0
M_VCF_1000 TO 1500 uL
1000
M_VCF_1500 TO 2000 uL
1000
M_DELTA_TSH
160
Legend
DELTA_TSH: minimum samples Delta value (see paragraph 3.1.5 Reading viewer – Pag.
2/4) to perform ESR correction according to volume.
N_VCF: for normal test tubes.
P_VCF: for pediatrics test tubes.
M_VCF: for MAP test tubes.
