8 ATTACHMENT C: SPARE PARTS LIST
Code
Description
10806820
MATRICULAR LABEL VES MATIC MINI CUBE
21890040
220Vac CABLE 3x0.75 L=2m SCHUKO 90° - C1
21890360
USB CABLE 1.1 A-B M/M 1,5 Mt
21890370
220Vac CABLE SVT PLUG USA/SOCKET VDE 2MT
30229430
MINI-CUBE NEW ANALYSIS MODULE ASS'Y
10341731
ANALISIS UNIT SCREW
10141731
ANALISIS UNIT SCREW
10603830
SAMPLES TUBE
10603840
BACK CABLE CLAMP
10603850
CABLE CLAMP PLATE
10603860
READING SENSOR BOARD SUPPORT SLIDING SIDE
10606900
BACK PANEL MINI-CUBE
10606920
MINI-CUBE BASEMENT LID
10809890
MINI-CUBE CENTRAL BODY SCREEN PRINTED
11505720
IGUS POLYMER BUSHING J3SM-0507-05
30111640
PHOTOSENSOR WIRED BOARD L=260
30113900
CABL. FOTOCELLULA
30117832
WIRED COIL
30136060
CONNECTION BOARD EXTERNAL CONNECTIONS
30138200
CHASSIS GROUND WIRING MINI CUBE
30221140
MINI-CUBE READING CART ASS'Y
10603810
MINI-CUBE READING SENSOR BOARD SUPPORT
10603820
MINI-CUBE READING SENSOR BOARD SUPPORT CLAMP
30136081
READING SENSORS 4x BOARD
10603711
MINI-CUBE READING SENSOR COVER
30136090
SINGLE READING SENSOR BOARD
30136110
BACKPLANE READING SENSOR BOARD
30144650
SINGLE READ SENSOR BOARD (LED ONLY)
30136460
CABL. FFC P=1.27mm 10V 35cm F-F POLAR. INVERSA UL
30228880
MINI-CUBE BASEMENT ASS'Y
10809040
MINI-CUBE BASEMENT SCREEN PRINTED
30228890
MINI-CUBE FRONTAL PLATE ASS'Y
10602780
DISPLAY FRAME
