H-PRO / L-PRO: Number of Record Tube contained in the message, represented in HEX-
ASCII.
The Record Tube number contained in the data field is limited by the fact that the data
field itself is able to contain up to a maximum of 255 bytes, in any case the Record Tubes
are never cut off.
Record Tubes:
BARCODE: ASCII string with variable lengths, maximum of 15 characters allowed. This
is the barcode just as it is read by the Mini Cube Barcode Reader.
TERMINATOR: the string of barcodes terminates with the 0x10 byte. This is because the
length of this string is variable.
DATA ANALYSES: string of 6 characters without terminator, “DDMMYY” where: “DD” =
day of the month, from “01” to “31” ASCII.
“MM” = Month of the year, from “01” to “12” ASCII. “YY” = Year of the century, from “00” to
“99” ASCII.
TIME ANALYSES: string of 4 characters without terminator, “hhmm” where: “hh” = hour
of the day, from “00” to “23” ASCII.
“mm” = Minutes, from “00” to “59” ASCII.
VES: Value of the VES measured, ASCII string without terminator: from “ 0” (3 spaces +
‘0’) transmitted in the case of an error, to “ 140” (1 space + “140”). If the result is greater of
140 the string will be “>140”.
EXAMPLES, see following table:
H-FLAGS / L-FLAGS: Bitmap with 8-bit of the sample errors, represented in HEX-ASCII.
The following table illustrates the errors:
