NOTE:
NOTE:
IMPORTANT:
NOTE:
CAUTION:
6.3. DC ACTUATOR ASSEMBLY AND INSTALLATION
a. ASSEMBLE PROPER ADAPTER (IF REQUIRED)
s
i
m
NOTE:
b. INSTALLATION
CHAMPION & ORBIT 3/4” brass, Model
03-068
3/4” Gasket, Model 03-069
CHAMPION & ORBIT adapter 1”
brass RAINJET, RAIN BIRD &
ORBIT 3/4” & 1” plastic
Washer, Model 03-066
1” Gasket, Model 03-073
“O” Ring #3, Model 03-057
Large Seatwasher assembly for 3/4”
and 1” ORBIT, LAWN GENIE, IRRITROL,
Model 03-074
(Install with larger hole facing down.)
Main screw for seat washer
assembly, Model 03-072
LAWN GENIE/RICHDEL adapter
3/4” & 1” plastic, Model 03-067
“O” Ring #3, Model 03-057
Gasket for 3/4” valves
Model 03-070
Large Seatwasher assembly
for 3/4” and 1” ORBIT,
LAWN GENIE, IRRITROL, Model
03-074
(Install with larger hole facing down.)
Main screw for seat washer
assembly, Model 03-072
3/4” Seatwasher for
3/4” Brass valve
3/4” RAIN BIRD plastic
valve, Model 03-071
A
B
C
Manual Stem
Anti-Siphon Cap
Valve
Body
warning: FaiLUrE TO USE
waTErprOOF cOnnEcTOrS
wiLL vOid manUFacTUrEr’S
warranTy
To Next Page
