DG-GS4628E2 / DG-GS4628HPE-P Installation Guide
4

Storage Temperature
-40°C～ 70°C

Relative Humidity
5%～95%, non-condensing

Dimension
DG-GS4628E2: W×H×D 442mm×220mm×43.6mm
DG-GS4628HPE-P: W×H×D 440mmX260mmx43.6mm

Weight
DG-GS4628E2: about 2.42kg
DG-GS4628HPE-P: about 5.35kg

Average no trouble time
At least 21, 0000 hours MTBF
1.3 Description of Hardware
1.3.1 Front Panel
DG-GS4628E2 provides 24 10/100/1000Base-T ports, 4 1000Mb SFP ports, 1
Console port, 1 system reset button, 30 LEDs, 1 220V AC power socket and 1 grounding
screw.
The front panel of DG-GS4628E2 is shown as follow:
Fig 1- 8 Front Panel of DG-GS4628E2
DG-GS4628HPE-P provides 24 10/100/1000Base-T ports, 4 1000Mb SFP ports, 1
Console port, 1 system reset button, 30 LEDs.
The front panel of DG-GS4628HPE-P is shown as follow:
Fig 1- 10 Front Panel of DG-GS4628HPE-P
