DG-GS4628E2 / DG-GS4628HPE-P Installation Guide
Table 1- 8 DG-GS4628E2 system indicator description
The internal power is operating normally
Operating state is abnormal
Operating state is normal
Power is off or system is abnormal
Fig 1- 28 DG-GS4628HPE-P system LED diagram
Table 1- 11 DG-GS4628HPE-P system indicator description
The internal power is operating normally
Operating state is abnormal
Operating state is normal
Power is off or system is abnormal
1.3.4 Front Panel Port Description
Each port description is shown below:
