DG-GS4900SE Series Installation Guide
21
Step 3: Push SFP transceiver along the guide rail gently until you feel the transceiver snap
into place at the bottom of the line card.
Note: SFP transceiver supports the hot swap.
Caution!
Do not stare directly at the 2 fiber bores in the SFP transceiver when the switch is in
operation, otherwise the laser may hurt your eyes.
2.3.4 SFP+ extended module Installation
DG-GS4900SE series provide 10Gb slots. The procedure for installing the SFP+
10Gb fiber transceiver is shown below:
Step 1: Put on an ESD wrist strap (or antistatic gloves).
Step 2: Insert the SFP+ transceiver to the 10G optical port. Do not put the SFP+
transceiver up-side-down.
Step 3: Push the SFP+ transceiver gently until the optical module is mixed with the optical
port.
Note: the SFP+ 10Gb fiber transceiver is hot swappable.
Caution!
Do not stare directly at the 2 fiber bores in the fiber transceiver when the switch is in
operation, otherwise the laser may hurt your eyes.
2.3.5 Copper Cable/Fiber Cable Connection
Copper cables should be connected as below:
Step 1: Insert one end of the Ethernet cable to the RJ-45 Ethernet port in the copper cable
line card of the switch;
Step 2: Insert the other end of the Ethernet cable to the RJ-45 Ethernet port of other
device;
Step 3: Check all status indicators for the corresponding ports; a lighted LED indicates
