Front and Back Panel Components
1-6 Product Description
Back Panel Components
Table 1-2 describes back panel components that are illustrated in Figure 1-2.
Figure 1-2: Back Panel Components
Table 1-2: Back Panel Component Descriptions
Item Name Description
1 Fan Expels hot air from inside the DECserver.
2 Power Connector Receives ac current from an outlet (115/230 Vac, 50/
60 Hz).
3505-04
2
DECserver 716
DECserver 732
1
