Cabling Requirements 4-5
Cabling Requirements
Cabling Requirements
Table 4-2 shows the maximum communication distances for different types of cables
used between the DECserver and the Ethernet device. Table 4-3 shows the maximum
cable lengths for a number of data rates using DECserver supported line protocols.
The cabling requirements of the DECserver are shown in the following sections.
Table 4-2: Maximum Communications Distances—Ethernet
Table 4-3: Maximum Cable Lengths for Data Rates
From To
Maximum
Distance
Cable Type
DECserver Transceiver 50 m (164 ft) BNE3x-xx standard transceiver cable
DECserver Transceiver 12.5 m (41 ft) BNE4x-xx office transceiver cable
DECserver Repeater 100 m (328 ft) BN24Q cable (crossover type)
BN25G (straight-through type)
Line Protocol Data Rate (S/B) Cable Length
EIA/TIA-432-A/V.10 4.8K
9.6K
19.2K
38.4K
57.6K
115.2K
500 m (1500 ft)
280 m (900 ft)
150 m (500 ft)
85 m (280 ft)
30 m (100 ft)
12 m (40 ft)
EIA/TIA 423 9.6K
19.2K
38.4K
57.6K
115.2K
900 m (3000 ft)
300 m (1000 ft)
150 m (500 ft)
60 m (200 ft)
30 m (100 ft)
EIA/TIA-232-E/V.28 9.6K
19.2K
38.4K
57.6K
115.2K
60 m (200 ft)
30 m (100 ft)
15 m (50 ft)
6 m (20 ft)
3 m (10 ft)
