Seven-Segment Display Shows a “3”
A-10
Seven-Segment Display Shows a “3”
If the seven-segment display has a “3” after power up, the DECserver has a downline
loading problem.
To isolate and diagnose the problem, do the following:
The conditions under which a “3” may appear in the seven-segment display, and the
messages associated with each condition, are described in the following sections.
Downline Load Starts, Then Fails
Step Action
1 Connect a terminal to the console port of the DECserver, then power up
the terminal.
2 Configure the terminal to operate with a speed of 9600 bits per second
and a character size of 8 bits (no parity). (Refer to the specific terminal
user's guide if you need help setting up the terminal parameters.)
3 Read the message that appears on the terminal display.
Message: The following messages may appear on the console terminal at
various time intervals:
Local—912—[MOP] Load failure, timeout
Local—953—[IP] Attempting to locate load host, [ETHERNET]
Local—953—[MOP] Attempting to locate load host, [ISO8802]
Local—953—[MOP] Attempting to locate load host, [ETHERNET]
Local—955—[MOP] Host xx-xx-xx-xx-xx-xx LOCATED
[ETHERNET]
Local—956—[MOP] Requesting load from host xx-xx-xx-xx-xx-xx
Problem: The host system failed to complete the downline load to the
DECserver.
Correction: Copy the error message exactly as it appears on the console terminal
display and notify the network manager. For more information, refer
to the Network Access Software Problem Solving Guide.
