Electrical Requirements
C-4
Electrical Requirements
The power at the electrical outlet must match the requirements shown in
Table C-4.
The instructions assume that an appropriate ac power source is within 1.8 m (6.0 ft) of
DECserver.
Table C-4:
Electrical Requirements
Table C-5 shows the electrical output from the standard Ethernet/IEEE 802.3
connector.
Table C-5:
Standard Ethernet/IEEE 802.3 Connector Output
Parameter DECserver
Line voltage
a
a. The DECserver automatically selects the voltage range.
100–120 V rms/220–240 V rms
Frequency 50/60 Hz
Line current 1.0 A rms/.5 A rms
Power 42W
Parameter DECserver
Voltage + 12 V DC
Current 0.5 A Max
