1. Expression Pedal
This pedal is used to control the pitch bending amount of the selected Harmony,
Whammy, or Detune eect. Rocking it forward (toe down) increases the amount of pitch
bending while rocking it back (toe up) decreases the amount of pitch bending.
2. Harmony LEDs
One of these LEDs will light when a Harmony eect is selected. Harmony eects have dry
signal added to the eect signal.
3. Classic/Chords Switch
This switch toggles between the classic Whammy algorithm (Classic) and modern chordal
algorithm (Chords). The Classic setting is ideal for single note play while the Chords
setting is best suited for bending of full chords.
4. Selector Knob
This knob is used to select one of the Whammy, Harmony, or Detune eects.
5. Whammy LEDs
One of these LEDs will light when a Whammy eect is selected. Whammy eects do not
have dry signal added to the eect signal.
6. Detune LEDs
One of these LEDs will light when a Detune eect is selected. The Expression Pedal
controls the amount of Detune signal mixed with the dry signal.
