DigiTech JIMI HENDRIX EXPERIENCE User Manual

4. INDICATOR LED
This LED indicates the present
mode of the model selected:
OFF=bypass, GREEN=toe mode,
RED=heel mode 1,YELLOW=heel
mode 2. (Please refer to the
Control Table, Flexible
Output Mode
TM
, and
Calibrating the Expression
Pedal sections for more
information.)
5. (Tip) - HIGH
Controls the boost/cut of high
frequencies in the selected model.
5. (Ring) - LOW
Controls the boost/cut of low
frequencies in the selected model.
6. Power Supply Jack
Connect only the included
PS0913B (9V AC) power supply
to this jack. Note that the Jimi
Hendrix Experience™ is not
equipped for battery power.
7. (Tip) - REVERB
Controls the reverb level in the
selected model.
7. (Ring) - CONTROL
Model dependent. (Please refer to
the Control Table section for
more information.)
8. MODELS
This knob selects one of the seven
different signature Jimi Hendrix
tones.
1. “Purple Haze”
2. “Wind Cries Mary”
3. “Foxey Lady”
4. “Little Wing”
5. “All Along The
Watchtower”
6. “Voodoo Child (Slight Return)”
7. “Star Spangled Banner
(Live)”/“Machine Gun”
Please refer to the Control
Tables for a detailed explanation
of each model’s controls.
JHE Manual v4.1 9/19/05 3:12 PM Page 7
