26
Connection Diagrams
The following diagrams show different ways of hooking up your TimeBender
TM
.
Mono In/Mono Out
9VAC
1300mA
POWER
Connect your guitar to the
TimeBender
TM
’s Left input.
Connect the TimeBender’s
Left output to your amp’s
input.
Optional FS3X footswitch.
Optional expression pedal.
