2
USER INTERFACE & CONNECTORS
Top Panel
3
5
4
7
8
9
10
6
1. GUITAR FX Button
Press this button to add the built-in effects to your guitar signal. See 'Guitar FX' on page 12 for more
information.
2. PART Buttons
The TRIO can learn up to 3 different song parts (for example, a verse, chorus, and bridge). The PART 1, 2, and
3 buttons are used to select between these 3 parts. If a PART button is selected for a part which has not yet
been learned by the TRIO, the LEARN LED will flash red to indicate that the part needs to be learned. See
'Learning & Playing Song Parts' on page 10 for more information on using song parts.
3. ALT TIME Button
Pressing this button selects an alternate interpretation of the song's tempo. Usually this is either double
or half the current tempo since this can be ambiguous. The state of the ALT TIME button can be set
independently in each of the 3 song parts.
• Once a part has been learned, the ALT TIME LED will be either GREEN (regular time) or AMBER (alt
time). It will also flash (dimly) at the tempo of the current part.
• When a part is being played, during the last bar of that part, the ALT TIME LED will flash more brightly
to indicate that the loop is coming around to the beginning.
• The ALT TIME LED will be off if the part has not yet been learned. The LED flash rate depends on the
tempo detected for the song, the position of the tempo knob, and whether the alternate time is
selected. The LED flash rate will be in phase with each 1/4 note beat played by the drums and bass.
