68
SECTION 6 - APPENDIX
SPECIFICATIONS A/D Converter: 16 bit PCM
D/A Converter: 16 bit PCM
Sampling Frequency: 40 kHz
DSP Section:
Architecture: Static-Dynamic Instruction Set Computer (S-DISC™)
Digital Signal Path Width: 24 bits (144.5 dB)
Internal Data Path Width: 48 bits (289 dB)
Dynamic Delay Memory: 64k x 24 bits (1.68 seconds)
Static Delay Memory: 256 24-bit registers (6.55 milliseconds)
Data ALU Processing: 10.0 MIPS
Address ALU Processing: 15.0 MIPS
Multiplier Size: 24 bits x 24 bits
Input Section:
Connector: 1/4” Unbalanced TRS
Nominal Level: -8 dBu
Maximum Level: +10 dBu
Impedance: 470 kohms
Output Section:
Connector: 1/4” TRS
Nominal Level: +4 dBu
Maximum Level: +18 dBu
Impedance: 50 ohms
General:
Frequency Response: 20 Hz. - 20 kHz. +0, -3 dB
S/N ratio: Greater than 90 dB; ref = max signal, 22 kHz measurement
bandwidth
Total Harmonic Distortion: Less than 0.04% (1 kHz.)
Memory Capacity:
Factory: 128 programs, 33 algorithms
User: 128 programs, 33 algorithms
Power Requirements:
US and Canada: 120 V AC, 60 Hz
Japan: 100 V AC, 50/60 Hz
Europe: 230 V AC, 50 Hz
UK: 240 V AC, 50 Hz
Power Consumption: 30 watts
Dimensions: 19” (482 mm) W x 1.75” (44 mm) H x 9” (229 mm) D
Section 6 - Appendix
Valve FX Owner’s Manual
