DigiTech VOCAL 300 User Manual

Expression Pedal
Assigning a Parameter
The Vocal 300 includes a built-in Expression pedal. The Expression pedal is
used to control many of the Vocal 300’s effect parameters in real time. To
assign a parameter to the Expression pedal,do the following:
1.Select a User or Factory Preset.
2.Press the SELECT button until the Matrix’s last effect row LED begins
flashing.
3.Rotate the LOW knob to select the Expression pedal 1,2,or 3.
Note: You can assign three parameters to the Expression pedal per
preset.
4.Rotate the MIDRANGE knob to select the parameter the pedal will
control.
5.Rotate the HIGH knob to adjust the minimum value the pedal (toe up)
reaches.
6.Rotate the MASTER LEVEL knob to adjust the maximum value the pedal
(toe down) reaches.
7.Press the STORE button to store the changes. See page 5 for more
information on storing presets.
The following is a list of the parameters that can be assigned to the
Expression pedal:
Parameter Display Min Value Max Value
Voice Param 1 Varies Varies Varies
Voice Param 2 Varies Varies Varies
Voice Level Voxlvl 199
Effect Speed Speed 199
Effect Amount amount 199
Effect Level Fx lvl 099
Effect Mix Fx MIX 099
Whammy whmamt 199
Delay Feedback fback 1 99 R-hold
Delay In Level Dly in 099
Delay Out Level Dlyout 099
Reverb Decay Decay 199
Reverb In Level Rev in 099
Reverb Out Level Revout 099
Volume Pre Volpre ------ ------
Volume Post volpst ------ ------
6
Vocal 300 Manual 11/20/01 8:23 AM Page 6

DigiTech VOCAL 300 Specifications

General

Type	Vocal Effects Processor
MIDI	No
Phantom Power	Yes
Effects	Pitch Correction, Delay, Reverb
Presets	40 User / 40 Factory
Inputs	1 x XLR, 1 x 1/4"
Power Supply	9V AC adapter
