Digitus 16 PORT GIGABIT ETHERNET NETWORK SWITCH User Manual

User Manual
Publication date:September, 2007
Revision A3
47
4. Operation of
Web-based Management
This chapter would introduce how to manage your Web Smart Switch and
how to configure the 10/100/1000Mbps TP Ports and Gigabit TP/SFP Fiber dual
media ports on the switch via web user interfaces. Web Smart Switch provides 12
fixed Gigabit Ethernet TP ports and 4 optional Gigabit dual media ports. With this
facility, you can easily access and monitor the status like MIBs, port activity, and
multicast traffic through any ports on the switch.
The default values of 16-Port GbE Web Smart Switch are listed in the table
below:
IP Address
192.168.1.1
Subnet Mask
255.255.255.0
Default Gateway
192.168.1.254
Password
admin
Table 4-1
When the configuration of your Web Smart Switch is finished, you can
browse it by the IP address you set up. For instance, type
http://192.168.1.1 in the
address row in a browser, then the following screen (see Fig.4-1) would show up
and ask for your password input for login and access authentication. The default
password is “admin”. For the first time access, please enter the default password,
and click <Apply> button. The login process now would be completed.
Web Smart Switch supports a simplified user management function which
allows only one administrator to configure the switch at one time.
To optimize the display effect, we recommend Microsoft IE and 1024x768
display resolution.
