4-3-1. Statistics Overview
The function of Statistics Overview collects any information and provides the
counting summary about the traffic of the port, no matter the packet is good or bad.
In the Fig. 4-25, the window can show all ports’ counter information at the
same time. If the counting is overflow, the counter will be reset and restart counting.
Function name:
Statistics Overview
Function description:
Display the summary counting of each port’s traffic, including Tx Bytes, Tx
Frames, Rx Bytes, Rx Frames, Tx Errors and Rx Errors.
Parameters description:
Tx Bytes:
Total transmitted bytes.
Tx Frames:
The counting number of the packet transmitted.
Rx Bytes:
Total received bytes.
Rx Frames:
Publication date: Septembery, 2007
Revision A3
84
