“standby” ports become operational without user intervention.
Function name:
LACP Port Configuration
Function description:
Enable or disable LACP protocol, user is allowed to set the aggregation key
value.
Parameter description:
Protocol Enabled:
Just tick the check box (
;) to enable LACP protocol then press the
<Apply> button to apply.
Key Value:
It’s key for an aggregation. This must be an integer value between 1 and
255 or auto select by switch.
Fig. 4-11 LACP Port Configuration
Publication date:September, 2007
Revision A3
61
