11
F3 LIST:
The LIST function lets you broaden or narrow the scope of which ports the OSD
displays on the main screen.
Many of the OSD functions only operate on the computers that have been
selected for listing on the main screen with this function. The choices and their
meanings are given in the table below:
Choice Meaning
ALL Lists all of the ports on the installation.
QVIEW
Lists only the ports that have been selected as Quick
View Ports.
POWERED ON
Lists only the ports that have their attached computers
powered on.
POWERED ON +
QVIEW
Lists only the ports that have their attached computers
powered on and have been selected as Quick View
QVIEW + NAME
Lists only the ports that have been selected as Quick
View Ports and have name.
NAME Lists only the ports that have names
Move the highlight bar to the choice you want, then press [enter]. An icon
appears before the choice to indicate that it is the currently selected one.
After you make your choice and press [Enter], you return to the OSD main screen
with the newly formulated list displayed.
F4 QV:
QV function can select port as Quick View. Move the highlight bar to a port, press
[F4], an icon of up triangle appears. Press [F4] again, the icon disappears.
