12
F5 EDIT:
EDIT function creates or edits the name of a port. Press [F5], a pink edit box will
appear on the screen. Input name, and then press [Enter], the port is set a name
and it will also appear on the screen.
F6 SET:
SET function settings can be set to the administrator and the user to set the OSD
menu. The related functions and user rights related settings, such as
management settings login password, display mode, switch hotkey adjustment
and so on.
To Change Your Settings
1. Move the highlight bar to an option; press [Enter] to enter a setting option.
2. After selecting an item, the sub-menu and the further options provided will
appear. To select it, double-click the mouse or move the selection column
to the option, and then press the [Enter] key, an icon will appear. Select the
option before to indicate that the item has been selected. The settings are
described in the following table:
Settings
Function
OSD ACTIVATING HOTKEY
OSD Menu Activates hotkey combination
selection settings. [Alt]+[Alt] by default
SWITCH HOTKEY
KVM port switch hot-key combination
selection setting.
[SHIFT] [SHIFT] [NUM] by default
CHANNEL DISPLAY MODE
Port display mode selection
CHANNEL DISPLAY
DURATION
Select the Port form to display the Dwell
Time setting
CHANNEL DISPLAY
POSITION
Select the port form display location
settings
SCAN DURATION
Port scan dwell time setting
SET PASSWORD
User login password settings
SET SUPER PASSWORD The administrator login password settings
CLEAR THE NAME LIST
Clear the port name setting
