HEATER WALL SWITCH WIRING
DIAGRAM FOR 120/240 VOLT
(SEE SECTION C OR SECTION D FOR MAIN POWER CONNECTION)
14
FIREPLACE JUNCTION BOX
RED
–
2
WALL
SWITCH
RED
–
1
GROUND - G
