E. Flame Intensity Control
Adjusts the intensity of the ame and smoke e󰀨ect when the
unit has been activated.
Pressing the will decrease the ame e󰀨ect and pressing
the will increase the ame e󰀨ect. One beep will be heard
when the ame height has reached the minimum or maximum
level.
!
NOTE: A few moments will be required between
adjustment and a change to the ame e󰀨ect.
!
NOTE: During normal operation it is expected to see
some condensation of water on the media plate. This
will vary depending on ambient conditions and should be
considered normal.
!
NOTE: When the water tank is empty, the ame e󰀨ect
shuts OFF and the LED’s will blink.
F. Volume Control
Adjusts the volume of the wood re sound e󰀨ects.
On the unit: Pressing the will decrease the volume and
pressing the will increase the volume.
On the Remote and Tethered Controller: Pressing the
will turn the volume On and O󰀨.
Operation
Figure 1 Primary Side Controls
Remote Control and Tethered
Controller for CDFI1000P
Remote Control and Tethered
Controller for CDFI500P
Remote Control and Tethered
Controller for CDFI500-PRO and
CDFI1000-PRO
Secondary Side Controls - CDFI1000 only
WARNING: This unit must be properly installed before it
is used. Air intakes located below the unit are essential.
See “Installation” section of the Owner’s Manual for further
information.
There are three di󰀨erent control options available for the unit:
manual (under the media plate), tethered controller (must be
connected to the unit) and a remote control.
The CDFI1000P and the CDFI1000-PRO units have two
separate internal modules that are controlled by the settings
entered on the left side (primary). The primary side controls
include the power switch and standby button, whereas the
secondary side controls do not. Finer adjustment can be done
using the controls on the right module to have both modules
operating at the same level (secondary).
!
NOTE: When the unit is used in an environment where
background noise is very low, it may be possible to hear a
sound which is related to the operation of the ame e󰀨ect.
This is normal and should not be a cause for concern.
!
NOTE: Always ensure that the appliance is xed to the
framing in a level position.
Controls
A. On/O󰀨 Switch
Supplies power to the unit.
When the switch is set to the On position, the unit will emit one
beep. The unit will be in standby mode when it is rst powered
on. The unit can be operated using any of the control options
(onboard, tethered controller, or remote control).
!
NOTE: When the unit is rst turned on the lights will come
on and mist will appear 45 seconds later.
B. Standby
Turns the operation of the ame e󰀨ect on or o󰀨.
C. Blue tooth
Required for synchronization of the remote, see
synchronization instructions for more detail.
D. Test Mode
Used for troubleshooting issues - outlined in the Test Mode
section of this service manual.
Figure 2
B
A
C D E F
Tethered
Controller
!
NOTE: The icons
with 1 dot indicate
controls for the primary
and 2 dots indicate
controls for the secondary.
A
RELEASE FOR SAMPLING -----
HC
17-05-17
B
ARTWORK UPDATED AS PER DNA -----
HC
06-06-17
