To Next PageTo Next PageWhat does one blink mean on my Dimplex CDFI1000P Indoor Fireplace?
If your Dimplex Indoor Fireplace unit continuously blinks one time, remove enough water from the reservoir so that the level is below the maximum level.
Why won't my Dimplex CDFI1000P turn on with the remote?
If your Dimplex Indoor Fireplace does not turn on with the remote control, first, consult the Operation Section to ensure proper operation. Then, try installing new batteries in the remote control. Make sure the tethered controller is correctly installed, ensuring the connection has clicked into place and a red light is visible. Synchronize the remote to the unit; the unit will flash on and off during synchronization, and completion will be indicated with 5 beeps. Ensure the tethered controller is in an open area to receive the remote signal. If the blue light on the remote doesn't turn on when buttons are pressed, the remote control may be defective and needs replacement.
How to reduce smoke in Dimplex CDFI1000P Indoor Fireplace flame effect?
If the flame effect in your Dimplex Indoor Fireplace has too much smoke or is coming out too fast, it could be due to the flame effect control being set too high. Adjust the flame height on both the secondary and/or primary controls to reduce the smoke or speed. Also, check if the filter is missing from the fan housing and insert the fan filter if it is missing.
Why is the flame effect too low on my Dimplex CDFI1000P Indoor Fireplace?
If the flame effect is too low in your Dimplex Indoor Fireplace, first, adjust the flame height on both the secondary and/or primary controls, as the flame effect control may be set too low. If that doesn't work, check for insufficient air intake and enlarge the area for air to enter the unit, ensuring it reaches the bottom. A defective transducer could also be the cause, so consider replacing it.
How to fix uneven mist on a Dimplex CDFI1000P?
If mist is not coming out evenly from your Dimplex Indoor Fireplace, you can take the following steps: * Remove any condensation buildup on the mist outlet. * Adjust the feet under the unit to ensure it is level, front to back and side to side. * Rearrange the media to ensure it is not blocking airflow. * If the transducer is running in test mode, ensure that the emitter is clean and free of calcium deposits or scaling. If it is not running, replace the transducer with the provided additional transducer. * If you are using demineralized water, add 1/8 tsp of table salt to the water reservoir to introduce electrolytes, repeating only when mist is not being produced correctly. * Allow water to warm to room temperature.
What to do if water is appearing beneath Dimplex CDFI1000P Indoor Fireplace?
If water is appearing around your Dimplex Indoor Fireplace, ensure that all water connections are tight and fully inserted to prevent leaks. Also, reduce the water pressure to below 58 psi (8 bar) if the incoming water pressure is too high.
How to fix a Dimplex CDFI1000P Indoor Fireplace sump not filling?
If your Dimplex Indoor Fireplace sump is not filling from the refill bottle, ensure the unit is level. Place something under the bottle to slope it slightly toward the fill cap so that the water can easily flow to the water reservoir.
Why is my Dimplex CDFI1000P Indoor Fireplace not refilling and not showing error blinks?
If your Dimplex Indoor Fireplace unit is not refilling and is not giving error blinks when the water is too high or too low, the level sensor assembly may be defective and needs to be replaced.
What does two blinks mean on my Dimplex Indoor Fireplace?
If your Dimplex Indoor Fireplace unit continuously blinks twice, refill the water reservoir so that the level is above the minimum level.
Why won't the flame effect start on my Dimplex CDFI1000P?
If the Dimplex Indoor Fireplace flame effect will not start and there are no error blinks, note that mist will begin emitting after 45 seconds of operation. If flame is being produced but is not rising beyond the top cover, lift the top cover carefully while the unit is operating. If mist is produced but not rising, refer to section 3.5. Also, put the unit in test mode to test the transducer; if the transducer is running, ensure the emitter is clean and free of calcium deposits or scaling. If the transducer is not running, replace it with the provided additional transducer.
General| Model | CDFI1000P |
|---|---|
| Category | Indoor Fireplace |
| Type | Electric |
| Product Type | Fireplace Insert |
| Voltage | 120V |
| Heating Area | Up to 400 sq. ft. |
| Style | Traditional |
| Finish | Black |
| Flame Effect | Yes |
| Flame Technology | LED |
| Flame Color | Multi-color |
| Adjustable Thermostat | Yes |
| Overheat Protection | Yes |
| Installation | Insert |
| Wattage | 1000W |
| BTUs | 1, 000 BTUs |
| Control Type | Remote Control |
| Height | 23.5 in |
Instructions for plumbing the unit using a kit or standard tubing, ensuring local code compliance.
Steps for preparing the unit for operation, including removing the media plate and installing the controller.
Description of the primary controls like On/Off switch and module adjustments for flame effect.
Step-by-step guide on how to refill the unit's water tank, with cautions for cooling and cap tightening.
Information on purchasing genuine Dimplex accessories such as logsets and piercing kits.
