12 www.dimplex.com
Operation
WARNING: This electric re-
box must be properly installed
before it is used.
The unit has two separate internal
modules that are controlled by the
settings entered on the left side
(primary). Finer adjustment can
be done using the controls on the
right module to have both mod-
ules operating at the same level
(secondary).
There are three different control
options available for the unit:
manual (under the media tray),
tethered controller (must be con-
nected to the unit) and a remote
control.
!
NOTE: When the unit is used
in an environment where back-
ground noise is very low, it may
be possible to hear a sound which
is related to the operation of the
ame effect. This is normal and
should not be a cause for con-
cern.
!
NOTE: Always ensure that
the appliance is xed to the fram-
ing in a level position.
Controls
A. On/Off Switch
Supplies power to the unit.
!
NOTE: When the unit is rst
turned on the lights will come on
and mist will appear 45 seconds
later.
B
A
C D
Figure 4
E F
Figure 5
Remote
Control
Tethered
Controller
!
NOTE: The icons
with 1 dot indicate con-
trols for the primary and
2 dots indicate controls
for the secondary.
