bumped,struckordropped.Caremustbetakenwhenhandlingthe

glass.

Lower Light Bulb Requirements

Quantityoffour(4)clearchandelierorcandelabrabulbswithanE-12

(small)socketbase,60Wattrating.

CAUTION: Donotexceed60Wattsperlamp.

To replace the bottom light bulbs:

1. Liftupthefrontedgeoftheloguntilitclearsthefronttabs.Pullout

untilthereartabclearsthebackledge,thenliftout(Figure13).

Figure 12

A B C

Removing

Glass

Replacing

Glass

Holding

Glass

Retaining

Clip

Figure 13

Side Section

Front

Edge

Log

Emberbed

Back

Ledge

Rear

Tab

Figure 14

Liftingout

Log

EmberBed

2. Examinethebulbstodeterminewhichbulbsrequirereplacement.

3. Holdthesocketwhileunscrewingthebulb.

4. Holdthesocketwhilescrewinginthenewbulb.
