Figure 1
SerialNumber
ModelNumber
PartNumber
Model and Serial Number Information
Ifyouhaveanyquestionsaboutourproductspleasehavetheproduct
modelandserialnumbersavailableuponcallingDimplexcustomer
service.Tolocatethemodelandserialnumberseebelow(Figure1).
XXXXX
SERIALNo.
Site Selection and Preparation
Thissectionprovideseasystepbystepinstructionsforselectinga
locationandpreparingthesitetoinstallthereplaceinto:
Existing replace•
New wall construction•
Dimplex mantel surround kit or custom made mantel surround•
!
NOTE: Thereplaceinsertcomescompletelyassembledand
wired.Sometoolsmayberequiredtopreparethesiteand
assembly/installthetrim.
 Thedimensionsofthereplaceinsertare26inches(66cm)wideX
22½inches(57.2cm)highX12inches(30.5cm)deep(Figure2).
Youshouldallow¼inch(0.6cm)aroundthereplaceinsertfor
easeofinstallation.
 Thisreplacedoesnotrequireanyventing.
