CAUTION: Clearance for air circulation beneaththereplaceinsert

isprovidedbythree(3)rubberfeet(Figure2).Do not install the

replace insert directly on carpet or similar surfaces which

may restrict air circulation.Ifinstallingthereplaceinacarpeted

area,placeaone-piece,solid,atsurfaceunderthereplace

insert.Ensurethatallthree(3)oftheinsert’sfeetrestsecurelyon

thissurface.

Existing Fireplace

1. Sealalldraftsandventswithnon-brousinsulationmaterialsto

preventchimneydebrisfromfallingintothereplaceinsert.Donot

installintoanexistingreplacethatispronetoleaksordampness.

2. Capthetopofthechimneyuetopreventrainfromentering.

3. Planyourelectricalpowersupply(refertoNOTE1).

4. Thepowercordcanrunalongthefrontofthehearthtoanoutlet

nearthereplace(Figure3).

NOTE 1: A15Amp,120Voltcircuitisrequired.Adedicatedcircuit

ispreferredbutnotessentialinallcases.Adedicatedcircuitwillbe

requiredif,afterinstallation,thecircuitbreakertripsorfuseblows

Figure 2

AirCirculationAreas

Rubber

Feet

22 ½”

(57.2cm)

26”(66cm)

12”

(30.5cm)
