Dimplex DF3003 - New Wall Construction

9
WARNING: Topreventpersonalinjuryyoushouldhirea
professionaltocapthechimneyueorcutaholeintheexisting
replaceforwiring.Ifyoureturnyourexistingreplacetoits
originaluse(example:woodburning),itshouldbeinspectedbythe
localbuildingdepartmentpriortousetoreducetheriskofreand
personalinjury.
New Wall Construction
1. Selectasuitablelocationthatisnotsusceptibletomoistureandis
awayfromdrapes,furnitureandhightrafc.
2. Placethereplaceinthedesiredlocationtoseehowitwilllookin
theroom.
3. Markthedesiredlocationontheoorandstorethereplaceina
safe,dryanddustfreelocation.
4. Usestudstoframeanopeningof303/4inch(78.1cm)wideX25
3/4inch(65.4cm)highX113/4inch(29.8cm)deep(Figure3).
5. Planyourelectricalpowersupply(refertoNOTE1).
Figure 3
30 3/4”
(78.1cm)
25 3/4”
(65.4cm)
11 3/4”
(29.8cm)
